Tinos H Flex
The Tinos H Flex offers unparalleled flexibility wrapped in a strikingly minimalist design that’s easy to clean. It has an elegant flat cover, a 2x1/2" middle connection and a valve insert which enables free choice of installation side. sleek, minimalist design
The steel panel radiator has an elegant flat cover in a distinctive cuboid shape defined by smooth lines, clean outer edges, and a flat front surface.
The Tinos H Flex is equipped with a 2x1/2" middle connection and a valve insert that can be changed from right to left without the need for a special left-hand design.
Optionally: app-enabled thermostatic valve head
This allows the radiator to be connected to a digital platform so that users can easily activate the radiator online and adjust the settings remotely.
Available in over 48 sizes and 72 different colours
| Properties | |
| Max operating temperature °C | 110 |
| Connection dimension | 2 x G 1/2 |
| Pressure rating | PN10 |
| Material | Steel |
| Standard colour | White RAL 9016 |
| Connections (ETIM) | MO |
| Types | 21; 22 |
| Heights [mm] | 300; 500; 600; 900 |
| Widths [mm] | 615; 815; 1015; 1215; 1415; 1615 |
ETIM MO Horizontal connection
Purmo radiators are warranted for a period of 10 years* from date of purchase against all manufacturing defects when they are used in normal conditions and for a heating system with hot water. The warranty does not apply to defects caused by installation or handling errors, misuse or factors external to the radiators, such as water quality or oxygen-permeable pipes.
Underfloor heating products and piping systems elements are warranted for a period of 10 years**.
* 6 years for galvanized radiators and 2 years for all electronic and electric components and spare parts sold separately (side covers, top grilles, plastic clips, plugs, air vents, fixing parts)
** 30 years for PexPenta pipes
CE certificate
| Document | Category |
|---|---|
| Data Sheet | Technical data sheet |
